Power mirror circuit for Mazda MX-5 NA (1989-1998)
Power mirror circuit
BLK WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
DOWN
DOWN UP
DRIVER SIDE PASSENGER SIDE
FUSE BLOCK (LEFT KICK PANEL)
HOT IN RUN AND ACC CIGAR FUSE
LEFT POWER OUTSIDE MIRROR
LEFT/ RIGHT MOTOR
LT GRN WIRE
LT GRN/BLK WIRE
POWER OUTSIDE MIRROR SWITCH
RIGHT LEFT
RIGHT POWER OUTSIDE MIRROR
UP/ DOWN MOTOR
UP/ DOWN MOTOR LEFT/ RIGHT MOTOR
