Mazda MX-5 NA (1989-1998) Heater circuit

Heater circuit

Car Wiring Diagrams for MX-5 Mazda NA (1989-1998): Heater circuit

1994 VFTC BLK WIRE BLOWER MOTOR BLOWER UNIT (BEHIND RIGHT SIDE OF I/P) BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE FUSE BLOCK HEATER CIRCUIT BREAKER HEATER CONTROL UNIT HOT IN RUN ME LO HI OFF RED WIRE RESISTOR
