Mazda MX-5 NA (1989-1998) starting/ charging engine controls wiring diagram
This page shows the only wiring diagram for the component.starting/ charging engine controls, which is found in the car Mazda MX-5 NA (1989-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
starting/ charging engine controls wiring diagram (1 of 1)
ABS FUSE
AD FAN FUSE
AIR CONDITIONING
ANTENNA FUSE
ANTI-LOCK BRAKES
BATTERY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
CIGAR FUSE
CIGARETTE LIGHTER
COOLING FAN FUSE
COOLING FANS
DEFOG FUSE
DEFOGGER
ENGINE CONTROLS, INSTRUMENT CLUSTER,
ENGINE FUSE
EXTERIOR LIGHTING
EXTERIOR LIGHTING ENGINE CONTROLS INTERIOR LIGHTING
EXTERIOR LIGHTING TRANSMISSION CONTROLS COMPUTER DATA LINES CRUISE CONTROL HORNS
FROM MAIN FUSE (DIAGRAM 1 OF 1) BTN FUSE
FUEL INJ FUSE
FUSE BLOCK (LEFT KICK PANEL)
FUSE BLOCK (LEFT KICK PANEL) TAIL FUSE
HAZARD FUSE
HEAD FUSE
HEADLIGHT SWITCH
HEADLIGHTS
HEATER CIRCUIT BREAKER
HEATER FUSE
IGNITION SWITCH
LT GRN WIRE
MAIN FUSE
MAIN FUSE BLOCK (RIGHT REAR CORNER OF ENGINE COMPARTMENT)
MAIN FUSE BLOCK (RIGHT REAR OF ENGINE COMPARTMENT)
MAIN FUSE BLOCK (RIGHT REAR OF ENGINE COMPT.)
METER FUSE
NCA WIRE
OFF
POWER ANTENNA
POWER WINDOWS)
PWR WINDOW FUSE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RETRACTOR FUSE
ROOM FUSE STOP FUSE
RUN WIRE
SOUND SYSTEMS POWER ANTENNA MIRRORS STARTING/ CHARGING
ST SIGN FUSE
STARTER
STARTING SYSTEM
STARTING/ CHARGING
STARTING/ CHARGING ENGINE CONTROLS
STARTING/ CHARGING INSTRUMENT CLUSTER CRUISE CONTROL ENGINE CONTROLS
TNS RELAY (LEFT REAR OF ENGINE COMPARTMENT)
TO BTN FUSE (DIAGRAM 1 OF 1)
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WIPER FUSE
WIPER/ WASHER EXTERIOR LIGHTING DEFOGGER HEADLIGHTS AIR CONDITIONING
Go to component -> Power distribution circuit -> STARTING/ CHARGING ENGINE CONTROLS
