Mazda MX-5 NA (1989-1998) room fuse 14 fuse 1 Wiring diagram
This page shows the only wiring diagram for the component.room fuse 14 fuse 1, which is found in the car Mazda MX-5 NA (1989-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram room fuse 14 fuse 1 (1 of 1)
1995 VFTC
AUDIO UNIT
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BLU/RED WIRE
BLU/WHT WIRE
BLU/YEL WIRE
CABLE)
CIGAR FUSE 15 FUSE 2
COMPACT DISC PLAYER (W/ CD PLAYER)
DRIVER'S LEFT HEADREST SPEAKER
DRIVER'S RIGHT HEADREST SPEAKER
FUSE BLOCK (LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT IN ACCY OR ON
LEFT DOOR SPEAKER
LT GRN/YEL WIRE
NCA WIRE
PASSENGER'S LEFT HEADREST SPEAKER
PASSENGER'S RIGHT HEADREST SPEAKER
POWER ANTENNA SYSTEM INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT DOOR SPEAKER
ROOM FUSE 14 FUSE 1
Go to component -> Base radio -> ROOM FUSE 14 FUSE 1
