Mazda MX-5 NA (1989-1998) right front turn/ hazard light left rear turn/ hazard light Wiring diagram
This page shows the only wiring diagram for the component.right front turn/ hazard light left rear turn/ hazard light, which is found in the car Mazda MX-5 NA (1989-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front turn/ hazard light left rear turn/ hazard light (1 of 1)
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU WIRE
BLU/YEL WIRE
BRAKE SWITCH (ON BRACKET, ABOVE BRAKE PEDAL)
DAYTIME RUNNING LIGHT (DRL) CONTROL MODULE (BEHIND LEFT SIDE OF I/P)
ENGINE CONTROLS SHIFT INTERLOCK ANTI-LOCK BRAKES CRUISE CONTROL
ENGINE CONTROLS SYSTEM
FLASHER UNIT (BEHIND LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/ORG WIRE
GRN/RED WIRE
GRN/WHT WIRE
GRN/YEL WIRE
HAZARD FUSE
HAZARD WARNING SWITCH
HEADLIGHT SWITCH PARK HEAD OFF
HEADLIGHTS SYSTEM (HEADLIGHT RELAY)
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN RUN AND START
HOT IN RUN FUSE BLOCK (BEHIND LEFT SIDE OF DASH) WIPER FUSE
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM (BRAKE IND)
JC-01 (REAR OF LEFT FRONT FENDER)
JC-02 (LEFT SIDE OF I/P)
LEFT
LEFT BRAKE LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT TURN/ HAZARD LIGHT
LEFT LICENSE LIGHT RIGHT LICENSE LIGHT
LEFT PARK LIGHT RIGHT PARK LIGHT
LEFT REAR SIDE MARKER LIGHT
LEFT TAILLIGHT
LEFT TURN IND
LT GRN WIRE
METER FUSE
NCA WIRE
ORG/ WIRE
PARKING BRAKE SWITCH (ON BASE OF PARKING BRAKE LEVER)
RED WIRE
RED/BLK WIRE
RIGHT
RIGHT BRAKE LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT TURN/ HAZARD LIGHT LEFT REAR TURN/ HAZARD LIGHT
RIGHT REAR SIDE MARKER LIGHT
RIGHT REAR TURN/ HAZARD LIGHT
RIGHT TAILLIGHT
RIGHT TURN IND
STOP FUSE
TAIL FUSE
TNS RELAY (LEFT REAR OF ENGINE COMPARTMENT)
TURN SWITCH
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, with drl -> RIGHT FRONT TURN/ HAZARD LIGHT LEFT REAR TURN/ HAZARD LIGHT
