Mazda MX-5 NA (1989-1998) front fog light, rear window defroster switch illumination Wiring diagram
This page shows the only wiring diagram for the component.front fog light, rear window defroster switch illumination, which is found in the car Mazda MX-5 NA (1989-1998). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front fog light, rear window defroster switch illumination (1 of 1)
1996 ONLY
ASHTRAY ILLUMINATION
BLK WIRE
BLU/RED WIRE
C-01
CRUISE CONTROL MAIN SWITCH ILLUMINATION
EXTERIOR LIGHTS SYSTEM (TNS RELAY)
FRONT FOG LIGHT, REAR WINDOW DEFROSTER SWITCH ILLUMINATION
FUSE BLOCK (LEFT KICK PANEL)
HAZARD WARNING, RETRACTABLE HEADLIGHT SWITCH ILLUMINATION
HOT AT ALL TIMES
HOT WITH HEAD OR PARK LIGHTS ON
I-01 PANEL LIGHT CONTROL SWITCH
I-02 HEATER CONTROL UNIT ILLUMINATION
I-03
I-09
I-10
I-11 TRUNK COMPART- MENT LIGHT SWITCH (1996 ONLY)
INSTRUMENT CLUSTER ILLUMINATION (4 USED)
INTERIOR LIGHT)
OFF
ON DOOR
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
ROOM FUSE
SELECTOR ILLUMINATION (A/T)
TAIL FUSE
TRUNK COMPARTMENT LIGHT (1996 ONLY)
WARNING SYSTEM (DOOR SWITCHES)
WHT/BLU WIRE
Go to component -> Interior light circuit -> FRONT FOG LIGHT, REAR WINDOW DEFROSTER SWITCH ILLUMINATION
