Door lock & keyless entry circuit for Mazda MPV II (1999-2003)

BLK WIRE BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/ORG WIRE BLU/RED WIRE DOOR LOCK CONTROL MODULE (BEHIND RIGHT SIDE OF DASH) DOOR LOCK FUSE DOOR LOCK SWITCH GRN WIRE GRN/RED WIRE HEADLIGHTS SYSTEM EXTERIOR LIGHT SYSTEM HORNS SYSTEMS HOT AT ALL TIMES HOT IN RUN OR START JC-02 (LEFT REAR OF ENGINE) JC-03 (BEHIND UPPER SIDE OF RIGHT KICK PANEL) JOINT BOX (AT LEFT KICK PANEL) KEYLESS CONTROL MODULE (IF EQUIPPED) (AT LEFT REAR SIDE OF VEHICLE) LEFT DOOR KEY CYLINDER SWITCH LEFT FRONT DOOR LOCK ACTUATOR LEFT FRONT DOOR SWITCH LEFT REAR DOOR SWITCH LOCK LOCK UNLOCK LT GRN WIRE METER FUSE ORG/ WIRE RED WIRE RED/BLK WIRE RIGHT DOOR KEY CYLINDER SWITCH RIGHT FRONT DOOR LOCK ACTUATOR RIGHT FRONT DOOR SWITCH RIGHT REAR DOOR SWITCH ROOM FUSE THEFT DETERRENT CONTROL MODULE (IF EQUIPPED) (BEHIND LEFT SIDE OF DASH) UN LOCK UNLOCK WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE

BLK WIRE BODY DOOR JOINT BOX (AT LEFT KICK PANEL) LEFT SLIDING DOOR CIRCUIT CONTACT (SLIDE DOOR CLOSE: ON) LEFT SLIDING DOOR LOCK ACTUATOR LIFTGATE LOCK ACTUATOR LOCK RED WIRE RED/BLK WIRE RIGHT SLIDING DOOR CIRCUIT CONTACT (SLIDE DOOR CLOSE: ON) RIGHT SLIDING DOOR LOCK ACTUATOR UN LOCK
