Mazda Millenia I facelift (2000-2003) keyless control module wiring diagram
This page shows the only wiring diagram for the component.keyless control module, which is found in the car Mazda Millenia I facelift (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
keyless control module wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
BRN/WHT WIRE
FUEL-FILLER LID OPENER (IN LUGGAGE COMPARTMENT, ON LEFT SIDE)
HOT AT ALL TIMES
JOINT BOX (UNDER LEFT SIDE OF DASH)
KEYLESS CONTROL MODULE
OPENER FUSE
TRUNK LID CANCEL SWITCH
TRUNK LID OPENER (ON CENTER REAR OF LUGGAGE COMPARTMENT)
TRUNK LID OPENER RELAY (BEHIND REAR SEAT, ON RIGHT SIDE)
TRUNK, FUEL-FILLER LID OPENER SWITCH
VIO WIRE
WHT WIRE
YEL WIRE
YEL/GRN WIRE
