Heated seats circuit for Mazda Millenia I (1994-2000)
Heated seats circuit
BLK WIRE
BLK/WHT WIRE
BLU/GRN WIRE
BLU/WHT WIRE
GRN WIRE
HOT AT ALL TIMES S WARM FUSE
HOT IN RUN AND START JOINT BOX (UNDER LEFT SIDE OF DASH) A/C FUSE
JC-01 (RIGHT FRONT DOOR SILL)
JC-11 (RIGHT FRONT DOOR SILL)
LEFT FRONT POWER SEAT SWITCH
LEFT FRONT SEAT WARMER SWITCH
LEFT SEAT WARMER UNIT
MAIN FUSE BOX (ON LEFT FRONT INNER FENDER PANEL)
RIGHT FRONT POWER SEAT SWITCH
RIGHT FRONT SEAT WARMER SWITCH
RIGHT SEAT WARMER UNIT
SEAT WARMER RELAY (BEHIND RIGHT REAR SEAT)
WHT/RED WIRE
YEL/RED WIRE
