Lane departure warning circuit, w/ camera for Mazda Flair Wagon III (2017-2023)
Lane departure warning circuit, w/ camera
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
BRN/YEL WIRE
CAMERA-BASED DRIVER ASSISTANCE SYSTEMS
CAMERA-BASED DRIVER SUPPORT SYSTEMS CAMERA HEATING
COMPUTER DATA LINES SYSTEM
DRIVER ASSISTANCE SYSTEM OPERATING FACILITY W/ HAZARD WARNING SWITCH
FRONT POWER DISTRIBUTION BOX
FUSE 44
FUSE 9
GRN WIRE
HOT W/ BI-STABLE RELAY ENERGIZED
HOT W/ TERMINAL
LANE DEPARTURE WARNING CAMERA
NCA WIRE
ORG/ WIRE
POWER DISTRIBUTION
RED WIRE
RED/WHT WIRE
SYSTEM
WHT/BRN WIRE
YEL WIRE
YEL/BLK WIRE
YEL/WHT WIRE
