Heated mirrors circuit, w/ lin bus function for Mazda Flair Wagon III (2017-2023)
Heated mirrors circuit, w/ lin bus function
BLU/RED WIRE
BLU/YEL WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH BLOCK
FRONT POWER DISTRIBUTION BOX
FUSE 22
FUSE 509
HOT AT ALL TIMES
HOT W/
LEFT EXTERIOR MIRROR
LIN BUS SIG
MIRROR HEATER
PT CAN H
PT CAN L
RED WIRE
RED/GRY WIRE
RELAY ENERGIZED
RIGHT EXTERIOR MIRROR
SUPPLY
WHT/BRN WIRE
