Car Wiring Diagrams for Remote walk-in system circuit for Mazda CX-9 II facelift (2020-2024)

BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/RED WIRE C-06 C-64 C-67 C-68 COMPUTER DATA LINES SYSTEM HOT AT ALL TIMES HOT AT ALL TIMES FUSE BLOCK HOT W/ INTERIOR 2 FUSE LEFT WALK-IN ACTUATOR LEFT WALK-IN SWITCH NCA WIRE P SEAT RL FUSE PNK WIRE REAR ONE-TOUCH WALK-IN CONTROL MODULE RED WIRE RELAY & FUSE BLOCK RIGHT WALK-IN ACTUATOR RIGHT WALK-IN SWITCH VIO WIRE WHT WIRE
