Car Wiring Diagrams for Rear heated seats circuit, bench seat for Mazda CX-9 II facelift (2020-2024)

0740-202 BLK WIRE BLK/BLU WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLK WIRE C-13 C-64 C-67 C-68 C-69 FUSE BLOCK GRN WIRE HOT AT ALL TIMES LEFT SECOND-ROW SEAT WARMER UNIT (SEAT BACK SIDE) LEFT SECOND-ROW SEAT WARMER UNIT (SEAT CUSHION SIDE) NCA WIRE REAR CLIMATE CONTROL UNIT REAR SEAT WARM FUSE RELAY & FUSE BLOCK RELAY ENERGIZED RIGHT SECOND ROW WARMER UNIT (SEAT CUSHION SIDE) RIGHT SECOND-ROW SEAT WARMER UNIT (SEAT BACK SIDE) SECOND ROW SEAT WARMER CONTROL UNIT
