Car Wiring Diagrams for Auto dimming mirror circuit, 10-pin w/ i terminal for Mazda CX-9 II facelift (2020-2024)

0912-502 AUTO DIMMING REAR VIEW MIRROR BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BLU/BLK WIRE BRN WIRE C-13 C-16 COMPUTER DATA LINES SYSTEM HOT AT ALL TIMES INTERIOR FUSE PNK WIRE RBCM (LEFT SIDE OF LUGGAGE COMPT) RELAY & FUSE BLOCK RELAY ENERGIZED VIO WIRE W/ SHORT CORD WHT/BLK WIRE
