Car Wiring Diagrams for Adaptive front lighting circuit for Mazda CX-9 II facelift (2020-2024)

A/C FUSE AFS CONTROL MODULE/ AUTO LEVELING CONTROL MODULE BLK WIRE BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRN/RED WIRE GRY WIRE HOT AT ALL TIMES HOT W/ INSTRUMENT CLUSTER LT BLU WIRE LT GRN WIRE LT GRN/RED WIRE METER 1 FUSE MICROCOMPUTER NCA WIRE ORG/ WIRE PNK WIRE PNK/GRN WIRE RED WIRE RELAY & FUSE BLOCK SRS 1 FUSE VIO WIRE W/ AFS WARNING/ INDICATOR LIGHTS WHT/BLK WIRE WHT/RED WIRE
