Mazda CX-9 II facelift (2020-2024) tcs off/ off- road traction assist switch Wiring diagram
This page shows the only wiring diagram for the component.tcs off/ off- road traction assist switch, which is found in the car Mazda CX-9 II facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tcs off/ off- road traction assist switch (1 of 1)
BLK WIRE
BLU WIRE
BRAKE FLUID LEVEL SENSOR
BRAKE FLUID LEVEL SW
BRN WIRE
BUZZER
C-04
C-07
CAN H (PCM)
CAN L (PCM)
COMPUTER DATA LINES SYSTEM
DIMMER CANCEL SWITCH
FBCM
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HS CAN-H
HS CAN-L
ILLUMINATION
INSTRUMENT CLUSTER
INTERIOR FUSE
LCD
LDWS OFF IND
LDWS OFF SWITCH
LEFT THIRD-ROW BUCKLE SWITCH
LEFT THIRD-ROW BUCKLE SWITCH/ RIGHT THIRD-ROW BUCKLE SWITCH
LT BLU WIRE
LT GRN WIRE
METER 1 FUSE
MICROCOMPUTER
MONITOR SWITCH
MS CAN-H
MS CAN-L
NAVIGATION SYSTEM
PANEL LIGHT CONTROL
PARKING SENSOR IND
PARKING SENSOR SWITCH
PLG FRONT SWITCH/ CLUSTER SWITCH
PNK WIRE
PNK/BLK WIRE
RED WIRE
RELAY & FUSE BLOCK
RELAY ENERGIZED
RIGHT THIRD-ROW BUCKLE SWITCH
SHIFT INTERLOCK SYSTEM
SOUND SYSTEMS
SPEEDOMETER
TACHOMETER
TAN WIRE
TCS OFF/ OFF- ROAD TRACTION ASSIST SWITCH
TCS OFF/ OFF-ROAD TRACTION ASSIST IND
TRANSMISSIONS SYSTEM
TRIPMETER SWITCH
VIO WIRE
W/ PASSENGER AIR BAG DEACTIVATION (PAD) INDICATOR
W/O REAR SEAT BELT REMINDER UNIT
W/O SECOND CONSOLE
WARNING SYSTEMS
WARNING/ INDICATOR LIGHTS
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> TCS OFF/ OFF- ROAD TRACTION ASSIST SWITCH
