Mazda CX-9 II facelift (2020-2024) gmsl in Wiring diagrams
This page contains all the electrical diagrams for the component. gmsl in, in which he is found in the car Mazda CX-9 II facelift (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram gmsl in (1 of 2)
0920-713
360 DEGREE VIEW MONITOR CONTROL MODULE
BLK WIRE
BLU WIRE
BRN WIRE
C-13
C-83
C-84
C-85
CAMERA
COMMANDER SWITCH
COMPUTER DATA LINES SYSTEM
CONNECTIVITY MASTER UNIT
DATA N
DATA P
DATA P V BUS
GMSL IN
GMSL OUT DISP
GNSS
GPS ANTENNA
GRN WIRE
GRY WIRE
LT BLU WIRE
LT GRN WIRE
MIC GND
MIC IN N
MIC IN P
MIC PWR
MOST IN N
MOST IN P
MOST OUT N
NAVIGATION SYSTEM (TELEMATICS CIRCUIT)
NCA WIRE
OUT
PBLC CAN H
PBLC CAN L
PNK WIRE
PWR CTRL OUT
REAR MOUNT CAMERA
RED WIRE
SHIELD
SHIELD MOST OUT P
UART
USB PORT/SD CARD SLOT HUB
V-BUS
VIO WIRE
W/ 360 DEGREE VIEW MONITOR SYSTEM
W/ TELEMATICS COMMUNICATION UNIT
W/O 360 DEGREE VIEW MONITOR SYSTEM
W/O TELEMATICS COMMUNICATION UNIT
WAKEUP OUT
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Navigation circuit, early production w/o bose (2 of 3) -> GMSL IN
