Mazda CX-9 II facelift (2020-2024) connector 10-pin w/ i terminal Wiring diagram
This page shows the only wiring diagram for the component.connector 10-pin w/ i terminal, which is found in the car Mazda CX-9 II facelift (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram connector 10-pin w/ i terminal (1 of 1)
0616-101
0616-102
0912-502
ACTIVE DRIVING DISPLAY
AUTO DIMMING REAR VIEW MIRROR
AUTO LIGHT SENSOR/ HUMIDITY SENSOR/ RAIN SENSOR
AWD CONTROL MODULE
BENCH SEAT
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BRN WIRE
C-02
C-04
C-13
C-16
C-19
C-24
C-25
C-26
C-49
C-50
C-64
C-80
C-82
CLOCKSPRING
CONNECTOR 10-PIN W/ F TERMINAL
CONNECTOR 10-PIN W/ I TERMINAL
CONNECTOR 5-PIN
ELECTRIC PARKING BRAKE CONTROL MODULE
FBCM
FROM USB FUSE (DIAGRAM 2 OF 6)
FRONT CLIMATE CONTROL UNIT
FRONT SEAT WARMER CONTROL UNIT
GRN WIRE
GRY WIRE
HEATED STEERING WHEEL CONTROL UNIT
INDICATOR UNIT
LEFT BLIND SPOT MONITORING (BSM) CONTROL MODULE
LT BLU WIRE
NCA WIRE
PARKING ASSIST UNIT
PLG CONTROL MODULE
PLG FRONT SWITCH/ CLUSTER SWITCH
PNK WIRE
POWER WINDOW MAIN SWITCH/ POWER OUTER MIRROR SWITCH/ LEFT DOOR LOCK SWITCH
RADAR UNIT
REAR CLIMATE CONTROL UNIT
REAR ONE-TOUCH WALK-IN CONTROL MODULE
RED WIRE
RED/BLK WIRE
RELAY & FUSE BLOCK
RIGHT BLIND SPOT MONITORING (BSM) CONTROL MODULE
RIGHT DOOR LOCK SWITCH
SECOND ROW SEAT HEATER SWITCH
SECOND ROW SEAT WARMER CONTROL UNIT
SEPARATE SEAT
ST HEATER 2 FUSE
SUNROOF MOTOR
TCM
TO SRS 1 FUSE (DIAGRAM 5 OF 6)
VIO WIRE
W/ SEAT VENTILATION SYSTEM
W/ SHORT CORD
W/O SEAT VENTILATION SYSTEM
Go to component -> Power distribution circuit (4 of 6) -> CONNECTOR 10-PIN W/ I TERMINAL
