Mazda CX-9 I (2006-2012) 4wd circuit

AWD CONTROL MODULE (BEHIND LEFT END OF DASH) AWD IND AWD SOLENOID (NEAR REAR DIFFERENTIAL) BCM (BEHIND LEFT KICK PANEL) BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DIFFERENTIAL OIL TEMPERATURE SENSOR (ON REAR DIFFERENTIAL) DRIVE CIRCUIT INDICATOR SELECTOR FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) GRN WIRE GRN/ORG WIRE HOT AT ALL TIMES MAIN FUSE BLOCK ENG+B FUSE (LEFT REAR OF ENGINE COMPT) HOT IN ON OR START INSTRUMENT CLUSTER J/C 11 J/C C-37 (BEHIND CENTER OF DASH) J/C C-44 (LEFT KICK PANEL) JC-13 METER FUSE MICROCOMPUTER NCA WIRE RED WIRE WHT WIRE WHT/BLK WIRE YEL WIRE
