Memory systems circuit for Mazda CX-9 I (2006-2012)

0913-204 0913-209 BACK BLK WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FRONT FRONT TILT MOTOR, POSITION SENSOR (UNDER DRIVER'S SEAT) GRN WIRE HOT AT ALL TIMES JC-13 MAIN FUSE BLOCK (LEFT REAR OF ENGINE COMPT) NCA WIRE P SEAT L FUSE POSITION MEMORY CONTROL MODULE (UNDER DRIVER'S SEAT) REAR TILT MOTOR, POSITION SENSOR (UNDER DRIVER'S SEAT) RECLINER MOTOR, RECLINER POSITION SENSOR (IN DRIVER'S SEAT BACK) RED WIRE SLIDER MOTOR, SLIDE POSITION SENSOR (UNDER DRIVER'S SEAT)

BACKWARD BCM (BEHIND LEFT KICK PANEL) BLK/YEL WIRE BLU/RED WIRE BRN/YEL WIRE DRIVER SIDE POWER SEAT SWITCH LIFT SWITCH DOWN UP MEMORY 1 MEMORY 2 MEMORY 3 NCA WIRE POSITION MEMORY SWITCH RECLINER SWITCH FORWARD SET- SLIDE SWITCH FORWARD TILT SWITCH DOWN UP
