Cooling fan circuit, dual fans for Mazda CX-9 I (2006-2012)

BLK WIRE BLU/BLK WIRE BLU/GRY WIRE BRN/RED WIRE COOLING FAN MOTOR 1 COOLING FAN MOTOR 2 COOLING FAN RELAY 1 COOLING FAN RELAY 2 CYLINDER HEAD TEMPERATURE SENSOR (TOP FRONT OF ENGINE) DIODE (UNDER RIGHT SIDE OF DASH) ENG IGA FUSE ENGINE CONTROLS SYSTEM FAN 2 FUSE FAN 1 FUSE FAN CONTROL MODULE 1 (BEHIND LEFT COOLING FAN ASSEMBLY) FAN CONTROL MODULE 2 (BEHIND RIGHT COOLING FAN ASSEMBLY) FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) FUSE, RELAY BOX (CENTER FRONT OF ENGINE COMPT) GRN WIRE GRN/WHT WIRE GRY/GRN WIRE HOT AT ALL TIMES HOT IN ON OR START MAIN FUSE BLOCK (LEFT REAR OF ENGINE COMPT) NCA WIRE PCM (LEFT REAR CORNER OF ENGINE COMPT) RED WIRE RED/BLK WIRE RED/BLU WIRE WHT/BLK WIRE WHT/RED WIRE
