Mazda CX-9 I (2006-2012) bluetooth unit Wiring diagrams

This page contains all the electrical diagrams for the component. bluetooth unit, in which he is found in the car Mazda CX-9 I (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

bluetooth unit wiring diagram (1 of 4)

BLK WIRE BLU WIRE BLU/BLK WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BLUETOOTH UNIT BRN WIRE COMPUTER DATA LINES SYSTEM GRN WIRE GRN/WHT WIRE GRY/BLU WIRE HOT AT ALL TIMES MAIN FUSE BLOCK BOSE FUSE (LEFT REAR OF ENGINE COMPT) J/C C-46 (CENTER OF DASH) LEFT FRONT DOOR SPEAKER LEFT FRONT SPEAKER LT GRN WIRE LT GRN/RED WIRE MICROPHONE (FRONT CENTER OF ROOF) NCA WIRE PNK/BLK WIRE PNK/BLU WIRE RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER VIO WIRE WHT WIRE WHT/BLU WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE

Go to component -> Navigation circuit, with bose (2 of 3) -> BLUETOOTH UNIT

bluetooth unit wiring diagram (2 of 4)

AA AB AUTO DIMMING MIRROR AUXILIARY JACK BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BLUETOOTH UNIT COMPUTER DATA LINES SYSTEM FUSE BLOCK (BEHIND RIGHT SIDE OF DASH) GRN WIRE GRN/WHT WIRE HOT IN ACC OR RUN J/C C-37 (BEHIND CENTER OF DASH) LT GRN/RED WIRE MICROPHONE (FRONT CENTER OF ROOF) MIRROR FUSE NCA WIRE PNK/BLK WIRE PNK/BLU WIRE RED/BLU WIRE RED/YEL WIRE VIO WIRE W/ CAR NAVIGATION SYSTEM W/O CAR-NAVIGATION SYSTEM WHT/BLU WIRE

Go to component -> Navigation circuit, without bose (2 of 2) -> BLUETOOTH UNIT
