Radio circuit, with bose with navigation for Mazda CX-7 I (2006-2009)

0922-202 0922-203 AMP ANTENNA AUDIO CONTROL SWITCH AUDIO UNIT BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE CLOCK SPRING (IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM FUSE BLOCK (UNDER LEFT END OF DASH) GRN/ORG WIRE GRY/BLK WIRE GRY/RED WIRE GRY/VIO WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ON OR ACC NCA WIRE ORG/BLK WIRE OUTLET 1 FUSE P MIR FUSE REAR MOUNT CAMERA (W/ BACK GUIDE MONITOR) (LEFT SIDE OF LIFTGATE) RED WIRE ROOM FUSE SEEK+ VOL+ SEEK- MODE VOICE VOL (-) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE

AUDIO AMPLIFIER (FRONT OF LUGGAGE COMPT) AUDIOPILOT MICROPHONE (BEHIND LEFT SIDE OF DASH) BLK/BLU WIRE BLK/GRN WIRE BLK/RED WIRE BLU/BLK WIRE BLU/YEL WIRE BOSE FUSE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM GRY WIRE GRY/BLK WIRE GRY/ORG WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HOT AT ALL TIMES LEFT FRONT DOOR SPEAKER LEFT FRONT SPEAKER LEFT REAR DOOR SPEAKER LEFT REAR SPEAKER MAIN FUSE BLOCK (LEFT REAR OF ENGINE COMPT) ORG/BLU WIRE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT FRONT SPEAKER RIGHT REAR DOOR SPEAKER RIGHT REAR SPEAKER WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE WOOFER

BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU/RED WIRE BLU/YEL WIRE BRN/BLU WIRE BRN/WHT WIRE CAR- NAVIGATION UNIT (UNDER FRONT PASSENGER'S SEAT) COMPUTER DATA LINES SYSTEM GRN/ORG WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE INSTRUMENT CLUSTER MICROCOMPUTER MICROPHONE (FRONT CENTER OF ROOF) POWER TOPS SYSTEM RED WIRE W/ SUNROOF WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL/BLU WIRE
