Car Wiring Diagrams for Door lock circuit for Mazda CX-7 I (2006-2009)

BCM (BEHIND LEFT KICK PANEL) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/WHT WIRE BLK/YEL WIRE D LOCK FUSE DOOR IND DRIVER SIDE DOOR KEY CYLINDER SWITCH/ DRIVER SIDE DOOR LOCK LINK SWITCH FUSE BLOCK GRN/RED WIRE HOOD LATCH SWITCH (CENTER FRONT OF ENGINE COMPT) HOT AT ALL TIMES INSTRUMENT CLUSTER KEYLESS CONTROL MODULE (W/ ADVANCED KEYLESS SYSTEM) (BEHIND RIGHT KICK PANEL) LEFT DOOR LOCK SWITCH LEFT FRONT DOOR LOCK ACTUATOR (AT REAR OF LEFT FRONT DOOR) LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR) LEFT REAR DOOR LOCK ACTUATOR (AT REAR OF LEFT REAR DOOR) LEFT REAR DOOR LOCK LINK SWITCH (IN LEFT REAR DOOR) LEFT REAR DOOR SWITCH (AT LEFT "C" PILLAR) LIFTGATE DOOR LOCK MOTOR (LOWER CENTER OF LIFTGATE) LOCK MAIN FUSE BLOCK (LEFT REAR OF ENGINE COMPT) MICROCOMPUTER RED WIRE RIGHT DOOR LOCK SWITCH RIGHT FRONT DOOR LOCK ACTUATOR (AT REAR OF RIGHT FRONT DOOR) RIGHT FRONT DOOR LOCK-LINK RIGHT FRONT DOOR SWITCH (AT RIGHT "B" PILLAR) RIGHT REAR DOOR LOCK ACTUATOR (AT REAR OF RIGHT REAR DOOR) RIGHT REAR DOOR LOCK LINK SWITCH (IN RIGHT REAR DOOR) RIGHT REAR DOOR SWITCH (AT RIGHT "C" PILLAR) ROOM (UNDER FUSE LEFT END OF DASH) SWITCH UNLOCK UNLOCK LOCK WHT/BLK WIRE WHT/RED WIRE YEL/BLK WIRE
