Mazda CX-7 I (2006-2009) Instrument cluster circuit

1-6 A/T IND A/T IND DRIVE CIRCUIT W/ DIMMER ABS IND. AIR BAG IND BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/ORG WIRE BLK/RED WIRE BLK/YEL WIRE BLU/RED WIRE BODY CONTROL MODULE (BCM) (BEHIND LEFT KICK PANEL) BRAKE FLUID LEVEL SENSOR (LEFT REAR OF ENGINE COMPT, IN BRAKE FLUID RESERVOIR) BRAKE IND BRN/BLU WIRE BRN/RED WIRE BUZZER CHARGE IND CHECK ENGINE IND COMPUTER DATA LINES SYSTEM CRUISE MAIN IND CRUISE SET IND DIMMER CANCEL SWITCH DOOR IND DSC IND F-FOG IND FUEL GAUGE FUEL GAUGE SENDER SUB UNIT (UNDER REAR SEAT, ON FUEL TANK) FUEL GAUGE SENDER UNIT (UNDER REAR SEAT, ON FUEL TANK) FUSE BLOCK (UNDER LEFT END OF DASH) GRN WIRE GRN/RED WIRE GRY/ORG WIRE GRY/RED WIRE HEADLIGHTS SYSTEM WIPER/WASHER SYSTEM HOT AT ALL TIMES HOT IN ON OR START INSTRUMENT CLUSTER KEY (GREEN) KEY (RED) WIRE LEFT FRONT DOOR SWITCH (AT LEFT FRONT "B" PILLAR) LEFT REAR DOOR SWITCH (AT LEFT REAR "C" PILLAR) METER FUSE MICRO COMPUTER ODOMETER/ TRIPMETER OIL IND OIL PRESSURE SWITCH (LOWER LEFT REAR OF ENGINE) ORG/BLU WIRE PARKING BRAKE SWITCH (AT BASE OF PARKING BRAKE ASSEMBLY) RED WIRE RED/GRN WIRE RIGHT FRONT DOOR SWITCH (AT RIGHT FRONT "B" PILLAR) RIGHT REAR DOOR SWITCH (AT RIGHT REAR "C" PILLAR) ROOM FUSE SEAT BELT IND SECURITY IND SPEEDOMETER TACHOMETER TNS TPMS IND TRIPMETER SWITCH WASHER IND WATER TEMPERATURE GAUGE WHT WIRE WHT/GRN WIRE WHT/RED WIRE
