Mazda CX-7 I (2006-2009) right rear speaker Wiring diagrams
This page contains all the electrical diagrams for the component. right rear speaker, in which he is found in the car Mazda CX-7 I (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear speaker (1 of 3)
AUDIO AMPLIFIER (FRONT OF LUGGAGE COMPT)
AUDIOPILOT MICROPHONE (BEHIND LEFT SIDE OF DASH)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BOSE FUSE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SPEAKER
LEFT FRONT SPEAKER
LEFT REAR DOOR SPEAKER
LEFT REAR SPEAKER
MAIN FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
ORG/BLU WIRE
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT REAR SPEAKER
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
WOOFER
Go to component -> Navigation circuit, with bose (2 of 3) -> RIGHT REAR SPEAKER
Wiring diagram right rear speaker (2 of 3)
AUDIO AMPLIFIER (FRONT OF LUGGAGE COMPT)
AUDIOPILOT MICROPHONE (BEHIND LEFT SIDE OF DASH)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BOSE FUSE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR SPEAKER
LEFT FRONT SPEAKER
LEFT REAR DOOR SPEAKER
LEFT REAR SPEAKER
MAIN FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
ORG/BLU WIRE
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT REAR SPEAKER
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/VIO WIRE
WOOFER
Go to component -> Radio circuit, with bose with navigation (2 of 3) -> RIGHT REAR SPEAKER
Wiring diagram right rear speaker (3 of 3)
8 0922-202
8 0922-203
ANTENNA
ANTENNA AMP
AUDIO AMPLIFIER (FRONT OF LUGGAGE COMPT)
AUDIO CONTROL SWITCH
AUDIO UNIT
AUDIOPILOT MICROPHONE (BEHIND LEFT SIDE OF DASH)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/RED WIRE
BOSE FUSE (LEFT REAR OF ENGINE COMPT)
BRN/YEL WIRE
CLOCK- SPRING (IN STEERING WHEEL)
COMPUTER DATA LINES SYSTEM
FUSE BLOCK (UNDER LEFT END OF DASH)
GRY WIRE
GRY/BLK WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
LEFT FRONT DOOR SPEAKER
LEFT FRONT SPEAKER
LEFT REAR DOOR SPEAKER
LEFT REAR SPEAKER
MAIN FUSE BLOCK
MODE
NCA WIRE
ORG/BLK WIRE
ORG/BLU WIRE
P MIR FUSE
RED WIRE
RIGHT FRONT DOOR SPEAKER
RIGHT FRONT SPEAKER
RIGHT REAR DOOR SPEAKER
RIGHT REAR SPEAKER
ROOM FUSE
SEEK
VOICE
VOL (-)
WHT WIRE
WHT/BLK WIRE
WHT/RED WIRE
WHT/VIO WIRE
WOOFER
Go to component -> Radio circuit, with bose without navigation -> RIGHT REAR SPEAKER
