Mazda CX-7 I (2006-2009) outlet 1 fuse Wiring diagrams

0922-202 0922-203 ANTENNA ANTENNA AMP AUDIO CONTROL SWITCH AUDIO UNIT BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE CLOCK SPRING (IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM FUSE BLOCK (UNDER LEFT END OF DASH) GRN/ORG WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ON OR ACC LEFT REAR DOOR SPEAKER MODE SEEK- NCA WIRE ORG/BLK WIRE OUTLET 1 FUSE P MIR FUSE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER ROOM FUSE SEEK+ VOL+ VOICE VOL (-) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE

0922-202 0922-203 AMP ANTENNA AUDIO CONTROL SWITCH AUDIO UNIT BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE CLOCK SPRING (IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM FUSE BLOCK (UNDER LEFT END OF DASH) GRN/ORG WIRE GRY/BLK WIRE GRY/RED WIRE GRY/VIO WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ON OR ACC NCA WIRE ORG/BLK WIRE OUTLET 1 FUSE P MIR FUSE REAR MOUNT CAMERA (W/ BACK GUIDE MONITOR) (LEFT SIDE OF LIFTGATE) RED WIRE ROOM FUSE SEEK+ VOL+ SEEK- MODE VOICE VOL (-) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE

A/C FUSE AIR CONDITIONING SYSTEM AIR CONDITIONING SYSTEM SOUND SYSTEMS BLK WIRE BLK/RED WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BLU/YEL WIRE BODY COMPUTER SYSTEM BOSE FUSE ROOF FUSE (W/ BOSE) BTN FUSE D LOCK FUSE DRL FUSE EXTERIOR LIGHTS, HORNS SYSTEMS F WIP FUSE FOG FUSE FROM ENGINE FUSE (DIAGRAM 1 OF 2) FROM HAZARD FUSE (DIAGRAM 2 OF 2) FROM IGNITION SWITCH (DIAGRAM 1 OF 2) FUSE BLOCK (UNDER LEFT END OF DASH) HAZARD FUSE HEADLIGHT RELAY HEADLIGHTS SYSTEM HORN FUSE INTERIOR LIGHTS, INSTRUMENT CLUSTER, AIR CONDITIONING, SOUND, NAVIGATION SYSTEMS MAIN FUSE BLOCK (LEFT REAR OF ENGINE COMPT) NAVIGATION SYSTEM ACCESSORY SOCKET ORG/BLK WIRE ORG/BLU WIRE OUTLET 1 FUSE OUTLET 2 FUSE P MIR FUSE P SEAT FUSE A/C FUSE P WIND 2 FUSE P WIND FUSE PNK WIRE PNK/BLK WIRE PNK/BLU WIRE PNK/ORG WIRE PNK/YEL WIRE POWER TOPS SYSTEM POWER WINDOWS SYSTEM R WIP FUSE REAR ACCESSORY SOCKET (IF EQUIPPED) RED WIRE RED/BLU WIRE SEAT FUSE SEATS SYSTEM SOUND, MIRRORS, DOOR LOCKS, NAVIGATION SYSTEMS STOP FUSE TNS FUSE TNS RELAY TO TNS FUSE (DIAGRAM 2 OF 2) WIPER/WASHER SYSTEM WIPER/WASHER, POWER TOPS SYSTEMS YEL WIRE

0922-202 0922-203 ANTENNA ANTENNA AMP AUDIO CONTROL SWITCH AUDIO UNIT BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE CLOCK SPRING (IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM FUSE BLOCK (UNDER LEFT END OF DASH) GRN/ORG WIRE GRY WIRE GRY/BLK WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ON OR ACC LEFT REAR DOOR SPEAKER MODE SEEK- NCA WIRE ORG/BLK WIRE OUTLET 1 FUSE P MIR FUSE RED WIRE RIGHT FRONT DOOR SPEAKER RIGHT REAR DOOR SPEAKER ROOM FUSE SEEK+ VOL+ VOICE VOL (-) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE

0922-202 0922-203 AMP ANTENNA AUDIO CONTROL SWITCH AUDIO UNIT BLK/GRN WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE CLOCK SPRING (IN STEERING COLUMN) COMPUTER DATA LINES SYSTEM FUSE BLOCK (UNDER LEFT END OF DASH) GRN/ORG WIRE GRY/BLK WIRE GRY/RED WIRE GRY/VIO WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT IN ON OR ACC NCA WIRE ORG/BLK WIRE OUTLET 1 FUSE P MIR FUSE REAR MOUNT CAMERA (W/ BACK GUIDE MONITOR) (LEFT SIDE OF LIFTGATE) RED WIRE ROOM FUSE SEEK+ VOL+ SEEK- MODE VOICE VOL (-) WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/VIO WIRE YEL WIRE
