Mazda CX-7 I (2006-2009) driver side door key cylinder switch/ driver side door lock link switch Wiring diagrams
This page contains all the electrical diagrams for the component. driver side door key cylinder switch/ driver side door lock link switch, in which he is found in the car Mazda CX-7 I (2006-2009). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram driver side door key cylinder switch/ driver side door lock link switch (1 of 2)
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLK/YEL WIRE
D LOCK FUSE
DOOR IND
DRIVER SIDE DOOR KEY CYLINDER SWITCH/ DRIVER SIDE DOOR LOCK LINK SWITCH
FUSE BLOCK
GRN/RED WIRE
HOOD LATCH SWITCH (CENTER FRONT OF ENGINE COMPT)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
KEYLESS CONTROL MODULE (W/ ADVANCED KEYLESS SYSTEM) (BEHIND RIGHT KICK PANEL)
LEFT DOOR LOCK SWITCH
LEFT FRONT DOOR LOCK ACTUATOR (AT REAR OF LEFT FRONT DOOR)
LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR)
LEFT REAR DOOR LOCK ACTUATOR (AT REAR OF LEFT REAR DOOR)
LEFT REAR DOOR LOCK LINK SWITCH (IN LEFT REAR DOOR)
LEFT REAR DOOR SWITCH (AT LEFT "C" PILLAR)
LIFTGATE DOOR LOCK MOTOR (LOWER CENTER OF LIFTGATE)
LOCK
MAIN FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
MICROCOMPUTER
RED WIRE
RIGHT DOOR LOCK SWITCH
RIGHT FRONT DOOR LOCK ACTUATOR (AT REAR OF RIGHT FRONT DOOR)
RIGHT FRONT DOOR LOCK-LINK
RIGHT FRONT DOOR SWITCH (AT RIGHT "B" PILLAR)
RIGHT REAR DOOR LOCK ACTUATOR (AT REAR OF RIGHT REAR DOOR)
RIGHT REAR DOOR LOCK LINK SWITCH (IN RIGHT REAR DOOR)
RIGHT REAR DOOR SWITCH (AT RIGHT "C" PILLAR)
ROOM (UNDER FUSE LEFT END OF DASH)
SWITCH
UNLOCK
UNLOCK LOCK
WHT/BLK WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> Door lock circuit -> DRIVER SIDE DOOR KEY CYLINDER SWITCH/ DRIVER SIDE DOOR LOCK LINK SWITCH
Wiring diagram driver side door key cylinder switch/ driver side door lock link switch (2 of 2)
BCM (BEHIND LEFT KICK PANEL)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/ORG WIRE
BLK/WHT WIRE
BLK/YEL WIRE
D LOCK FUSE
DOOR IND
DRIVER SIDE DOOR KEY CYLINDER SWITCH/ DRIVER SIDE DOOR LOCK LINK SWITCH
FUSE BLOCK
GRN/RED WIRE
HOOD LATCH SWITCH (CENTER FRONT OF ENGINE COMPT)
HOT AT ALL TIMES
INSTRUMENT CLUSTER
KEYLESS CONTROL MODULE (W/ ADVANCED KEYLESS SYSTEM) (BEHIND RIGHT KICK PANEL)
LEFT DOOR LOCK SWITCH
LEFT FRONT DOOR LOCK ACTUATOR (AT REAR OF LEFT FRONT DOOR)
LEFT FRONT DOOR SWITCH (AT LEFT "B" PILLAR)
LEFT REAR DOOR LOCK ACTUATOR (AT REAR OF LEFT REAR DOOR)
LEFT REAR DOOR LOCK LINK SWITCH (IN LEFT REAR DOOR)
LEFT REAR DOOR SWITCH (AT LEFT "C" PILLAR)
LIFTGATE DOOR LOCK MOTOR (LOWER CENTER OF LIFTGATE)
LOCK
MAIN FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
MICROCOMPUTER
RED WIRE
RIGHT DOOR LOCK SWITCH
RIGHT FRONT DOOR LOCK ACTUATOR (AT REAR OF RIGHT FRONT DOOR)
RIGHT FRONT DOOR LOCK-LINK
RIGHT FRONT DOOR SWITCH (AT RIGHT "B" PILLAR)
RIGHT REAR DOOR LOCK ACTUATOR (AT REAR OF RIGHT REAR DOOR)
RIGHT REAR DOOR LOCK LINK SWITCH (IN RIGHT REAR DOOR)
RIGHT REAR DOOR SWITCH (AT RIGHT "C" PILLAR)
ROOM (UNDER FUSE LEFT END OF DASH)
SWITCH
UNLOCK
UNLOCK LOCK
WHT/BLK WIRE
WHT/RED WIRE
YEL/BLK WIRE
Go to component -> Forced entry circuit -> DRIVER SIDE DOOR KEY CYLINDER SWITCH/ DRIVER SIDE DOOR LOCK LINK SWITCH
