Mazda CX-50 I (2021-2024) w/o 360 degree view monitor system Wiring diagram
This page shows the only wiring diagram for the component.w/o 360 degree view monitor system, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o 360 degree view monitor system (1 of 1)
0518-102
BLU WIRE
BRN WIRE
C-13
C-69
CAN L
CAN-H
DASH-ELECTRICAL SUPPLY UNIT (RIGHT SIDE OF DASH)
ELECTRICAL SUPPLY UNIT
FORWARD SENSING CAMERA (FSC)
GRN WIRE
GRY WIRE
HS CAN-H
HS CAN-L
J/C C-58
J/C C-72
J/C C-73
LEFT "C" PILLAR)
LT GRN WIRE
NCA WIRE
PARKING ASSIST UNIT (OPTICAL)/ 360 DEGREE VIEW MONITOR CONTROL MODULE
PLG CONTROL MODULE
PNK WIRE
PRVT
RED WIRE
SHIFT PANEL (INDICATOR)
TCM
W/ 360 DEGREE VIEW MONITOR SYSTEM
W/ BLIND SPOT MONITORING (BSM) SYSTEM
W/ PARKING SENSOR SYSTEM
W/ POWER LIFTGATE (PLG) SYSTEM
W/O 360 DEGREE VIEW MONITOR SYSTEM
W/O BLIND SPOT MONITORING (BSM) SYSTEM
W/O PARKING SENSOR SYSTEM
W/O POWER LIFTGATE (PLG) SYSTEM
WHT WIRE
YEL WIRE
Go to component: -> Computer data lines circuit (3 of 4) -> W/O 360 DEGREE VIEW MONITOR SYSTEM
