Mazda CX-50 I (2021-2024) tilt motor reclining motor Wiring diagram

This page shows the only wiring diagram for the component.tilt motor reclining motor, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram tilt motor reclining motor (1 of 1)

Wiring diagram tilt motor reclining motor for Mazda CX-50 I (2021-2024)

Get access

0913-601 0913-607 0913-608 BLK WIRE BRN WIRE BW DOWN BW FW C-21 C-61 C-91 DRIVER SIDE POWER SEAT SWITCH DRIVER-SIDE SEAT FUSE 11 FUSE BLOCK HOT AT ALL TIMES LIFTER MOTOR LIFTER SWITCH LUMBAR MOTOR LUMBAR SWITCH NCA WIRE RECLINING SWITCH RED WIRE SLIDE MOTOR SLIDE SWITCH TILT MOTOR RECLINING MOTOR TILT SWITCH UP BW DOWN

Go to component: -> Driver power seat circuit -> TILT MOTOR RECLINING MOTOR
