Mazda CX-50 I (2021-2024) tcu usb 2.0 gnd Wiring diagram
This page shows the only wiring diagram for the component.tcu usb 2.0 gnd, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram tcu usb 2.0 gnd (1 of 1)
0914-504
0914-505
0914-506
BLK WIRE
BLU WIRE
BRN WIRE
C-03
C-06
C-13
C-14
C-23
CAN H PBLC
CAN L PBLC
COMPUTER DATA LINES SYSTEM
CONNECTIVITY MASTER UNIT (CENTER OF DASH)
CRASH SIG
ENS 2 IN
ENS 2 OUT
FUSE 22
GND 2
GND 3
GND 4
GNSS
GNSS SIG
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
INDICATOR
INSTRUMENT CLUSTER
J/C C-41
J/C C-42
LIGHTS)
LT GRN WIRE
MICROCOMPUTER
NCA WIRE
PASSENGER'S FRONT DOOR)
PASSENGER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT
PNK AF WIRE
PNK ENS WIRE
PNK WIRE
PPL/BLK WIRE
PPL/YEL WIRE
RED WIRE
RELAY & FUSE BLOCK
RELAY 2 ENERGIZED
SAS CONTROL MODULE
TCU USB 2.0 DATA N
TCU USB 2.0 DATA P
TCU USB 2.0 GND
TCU USB 2.0 VBUS
TEL ANTENNA 1 (RIGHT CENTER OF DASH)
TEL ANTENNA 2
TEL SIG 1
TEL SIG 2
TELEMATICS COMMUNICATION UNIT
USB 1 DATA N
USB 1 DATA P
USB 1 GND
USB 1 VBUS
WARNING
WHT WIRE
YEL WIRE
Go to component: -> Telematics communication circuit -> TCU USB 2.0 GND
