Mazda CX-50 I (2021-2024) system pwr Wiring diagram
This page shows the only wiring diagram for the component.system pwr, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram system pwr (1 of 1)
0922-514
AJ GND SIG
AK CAN H PBLC
AM CAN L PBLC
AN IG DCDC
BLK WIRE
BLU WIRE
BRN WIRE
C-03
C-08
C-09
C-69
C-70
CAN-H
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
DC/DC -
F SEN GND
F SEN PWR
FUSE 16
FUSE 49
FUSE 54
FUSE 55
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
IGNITION RELAY
INSTRUMENT CLUSTER
J/C C-30
J/C C-58
LEFT FRONT CORNER ULTRASONIC SENSOR
LEFT FRONT ULTRASONIC SENSOR
LEFT REAR CORNER ULTRASONIC SENSOR
LEFT REAR ULTRASONIC SENSOR
LT BLU WIRE
LT GRN WIRE
MICROCOMPUTER
ORG/ WIRE
OUT
PARKING ASSIST UNIT
PNK CAN-L WIRE
PNK WIRE
POWER DISTRIBUTION SYSTEM
PPL/GRN WIRE
R SEN GND
R SEN PWR
RED WIRE
RELAY & FUSE BLOCK
RELAY 1 ENERGIZED
RELAY 2 ENERGIZED
RIGHT FRONT CORNER ULTRASONIC SENSOR
RIGHT FRONT ULTRASONIC SENSOR
RIGHT REAR CORNER ULTRASONIC SENSOR
RIGHT REAR ULTRASONIC SENSOR
SYSTEM GND
SYSTEM PWR
VIO WIRE
W/O I STOP SYSTEM
WARNING/ INDICATOR LIGHTS
WHT WIRE
YEL WIRE
Go to component: -> Parking assistant circuit -> SYSTEM PWR
