Mazda CX-50 I (2021-2024) retract/ return switch Wiring diagrams

This page contains all the electrical diagrams for the component. retract/ return switch, in which he is found in the car Mazda CX-50 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram retract/ return switch (1 of 2)

Wiring diagram retract/ return switch for Mazda CX-50 I (2021-2024)

Get access

ADJ COMMON ADJ SEL SW ADJ SSR GND ADJ SSR PWR ADJ SW ADJ X ADJ X SSR ADJ X SSR PNK ADJ SSR PWR WIRE ADJ Y ADJ Y SSR AUTO-DIMMING OUTER MIRROR BLIND SPOT MONITORING (BSM) WARNING LIGHT BLK WIRE BLU WIRE BRN WIRE C-22 C-23 CAN H PBLC CAN L CAN L PBLC CLUSTER B SIG CLUSTER SWITCH 2 COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DOWN DOWN UP DRIVER'S FRONT DOOR) DRIVER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT FOLD FOLD SW FUSE 16 FUSE BLOCK GRN WIRE GRY WIRE HEATED OUTER MIRROR HOT AT ALL TIMES ILL+ GND INSTRUMENT CLUSTER J/C C-46 LEFT LEFT POWER OUTER MIRROR LEFT RIGHT LT BLU WIRE LT GRN WIRE MEMORY 1 MEMORY 2 MIRRORS SYSTEM NAVIGATION SYSTEM NCA WIRE PASSENGER'S FRONT DOOR) PASSENGER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT PLG FRONT SWITCH PNK WIRE POWER OUTER MIRROR SWITCH RED WIRE RETRACT/ RETURN SWITCH RETURN RETRACT RIGHT RIGHT LEFT RIGHT POWER OUTER MIRROR SEL L IND SEL R IND SET- SIDE TURN LIGHT SW GND TAN WIRE UNFOLD UNFOLD PNK FOLD WIRE UP DOWN VIO WIRE W/ RETRACTABLE OUTER MIRROR WHT WIRE YEL WIRE

Go to component: -> Memory mirrors circuit -> RETRACT/ RETURN SWITCH

Wiring diagram retract/ return switch (2 of 2)

Wiring diagram retract/ return switch for Mazda CX-50 I (2021-2024)

Get access

ADJ COMMON ADJ SEL SW ADJ SSR GND ADJ SSR PWR ADJ SW ADJ X ADJ X SSR ADJ X SSR PNK ADJ SSR PWR WIRE ADJ Y ADJ Y SSR BLIND SPOT MONITORING (BSM) WARNING LIGHT BLK WIRE BLU WIRE BRN WIRE C-22 C-23 CAN L CAN-H COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DOWN DOWN UP DRIVER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT FOLD FOLD SW FUSE 16 FUSE BLOCK GRN WIRE GRY WIRE HEATED OUTER MIRROR HOT AT ALL TIMES ILL+ GND J/C C-46 LEFT LEFT POWER OUTER MIRROR LEFT RIGHT LT BLU WIRE LT GRN WIRE NAVIGATION SYSTEM NCA WIRE PASSENGER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT PNK WIRE POWER OUTER MIRROR SWITCH RED WIRE RETRACT/ RETURN SWITCH RETURN RETRACT RIGHT RIGHT LEFT RIGHT POWER OUTER MIRROR SEL L IND SEL R IND SIDE TURN LIGHT SW GND TAN WIRE UNFOLD UP DOWN VIO WIRE W/ RETRACTABLE OUTER MIRROR WHT WIRE YEL WIRE

Go to component: -> Power mirror circuit -> RETRACT/ RETURN SWITCH
