Mazda CX-50 I (2021-2024) recliner motor, position sensor Wiring diagram

This page shows the only wiring diagram for the component.recliner motor, position sensor, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram recliner motor, position sensor (1 of 1)

Wiring diagram recliner motor, position sensor for Mazda CX-50 I (2021-2024)

Get access

0913-311 BACK BLK WIRE CAN H PBLC CAN L PBLC CLUSTER B SIG CLUSTER SWITCH 2 COMPUTER DATA LINES SYSTEM DOWN DRIVER-SIDE SEAT FRONT INSTRUMENT CLUSTER LIFT MOTOR, POSITION SENSOR MEMORY 1 MEMORY 2 NCA WIRE PLG FRONT SWITCH RECLINER MOTOR, POSITION SENSOR RED WIRE SET- SLIDER MOTOR, POSITION SENSOR TILT MOTOR, POSITION SENSOR VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Memory seat circuit (2 of 2) -> RECLINER MOTOR, POSITION SENSOR
