Mazda CX-50 I (2021-2024) low fuel pressure sensor/ fuel temperature sensor Wiring diagram
This page shows the only wiring diagram for the component.low fuel pressure sensor/ fuel temperature sensor, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low fuel pressure sensor/ fuel temperature sensor (1 of 1)
0140-416
0140-418
0140-442
ACTIVE AIR SHUTTER (IF EQUIPPED)
BLK WIRE
BLU WIRE
BOOST PRESSURE SENSOR
BRN WIRE
C-02
C-71
C-75
CURRENT SENSOR
ELECTRIC WATER PUMP
ENGINE COOLANT TEMPERATURE SENSOR 1
ENGINE OIL LEVEL SENSOR
ENGINE OIL TEMPERATURE SENSOR/ENGINE OIL PRESSURE SENSOR
EXHAUST GAS PRESSURE SENSOR
GRN WIRE
GRY WIRE
LOW FUEL PRESSURE SENSOR/ FUEL TEMPERATURE SENSOR
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PNK WIRE
PPL/BLU WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT GRN WIRE
PPL/RED WIRE
PPL/YEL WIRE
RED WIRE
REFRIGERANT PRESSURE SENSOR 2
VIO WIRE
WASTEGATE VALVE
WHT WIRE
YEL WIRE
Go to component: -> Wiring diagram engine performance 2.5l turbo skyactiv (2 of 6) -> LOW FUEL PRESSURE SENSOR/ FUEL TEMPERATURE SENSOR
