Mazda CX-50 I (2021-2024) liftgate door lock switch Wiring diagrams

This page contains all the electrical diagrams for the component. liftgate door lock switch, in which he is found in the car Mazda CX-50 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram liftgate door lock switch (1 of 3)

Wiring diagram liftgate door lock switch for Mazda CX-50 I (2021-2024)

Get access

0914-118 BACKUP B+ MON BACKUP POWER SUPPLY (IF EQUIPPED) (UNDER DRIVER'S SEAT) BLK WIRE BLU WIRE BRN WIRE C-06 C-20 C-22 C-23 C-24 C-25 CAN-H 1 CAN-L 1 CARGO LAMP CARGO SW COMPUTER DATA LINES SYSTEM DOOR DOOR SW (RL) DOOR SW FL E LATCH MOTOR ELECTRICAL SUPPLY UNIT (LEFT SIDE OF LUGGAGE COMPT) FUEL LID L FUEL LID UL FUEL-FILLER LID LOCK ACTUATOR FUSE 48 GRN WIRE HOT W/ IGN 1 RELAY 2 ENERGIZED J/C C-51 J/C C-52 LATCH) LEFT REAR DOOR LATCH, LOCK ACTUATOR LIFTGATE DOOR LOCK SWITCH LIFTGATE LATCH, LOCK ACTUATOR LIFTGATE OPENER SWITCH LOCK LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RELAY & FUSE BLOCK RIGHT REAR DOOR LATCH, LOCK ACTUATOR UNLOCK VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Anti-theft circuit (3 of 4) -> LIFTGATE DOOR LOCK SWITCH

Wiring diagram liftgate door lock switch (2 of 3)

Wiring diagram liftgate door lock switch for Mazda CX-50 I (2021-2024)

Get access

0918-605 2.5L BCM BLK WIRE C-04 C-06 C-11 C-20 C-23 C-26 CARGO COMPARTMENT LIGHT (LIFTGATE SIDE) COOLING FAN MOTOR DASH-ELECTRICAL SUPPLY UNIT DATA LINK CONNECTOR 2 DOOR LOCK SWITCH (LIFTGATE)/ PLG REAR SWITCH DSC HU/CM EPS CONTROL MODULE FAN CONTROL MODULE HIGH MOUNT BRAKE LIGHT J/C C-47 LEFT LICENSE PLATE LIGHT LEFT LIFTGATE LIGHT LEFT POWER LIFTGATE DRIVE UNIT LIFTGATE DOOR LOCK SWITCH LIFTGATE LATCH, LOCK ACTUATOR LIFTGATE OPENER SWITCH NCA WIRE PASSENGER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT PCM REAR WINDOW DEFOGGER REAR WIPER MOTOR REMOTE TUNER (RT) RIGHT LIFTGATE LIGHT W/ POWER LIFTGATE SYSTEM W/O POWER LIFTGATE SYSTEM

Go to component: -> Ground distribution circuit (4 of 5) -> LIFTGATE DOOR LOCK SWITCH

Wiring diagram liftgate door lock switch (3 of 3)

Wiring diagram liftgate door lock switch for Mazda CX-50 I (2021-2024)

Get access

0914-118 BACKUP B+ MON BACKUP POWER SUPPLY (IF EQUIPPED) (UNDER DRIVER'S SEAT) BLK WIRE BLU WIRE BRN WIRE C-06 C-20 C-22 C-23 C-24 C-25 CAN-H 1 CAN-L 1 CARGO LAMP CARGO SW COMPUTER DATA LINES SYSTEM DOOR DOOR SW (RL) DOOR SW FL E LATCH MOTOR ELECTRICAL SUPPLY UNIT (LEFT SIDE OF LUGGAGE COMPT) FUEL LID L FUEL LID UL FUEL-FILLER LID LOCK ACTUATOR FUSE 48 GRN WIRE HOT W/ IGN 1 RELAY 2 ENERGIZED J/C C-51 J/C C-52 LATCH) LEFT REAR DOOR LATCH, LOCK ACTUATOR LIFTGATE DOOR LOCK SWITCH LIFTGATE LATCH, LOCK ACTUATOR LIFTGATE OPENER SWITCH LOCK LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RELAY & FUSE BLOCK RIGHT REAR DOOR LATCH, LOCK ACTUATOR UNLOCK VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Power door locks circuit (3 of 4) -> LIFTGATE DOOR LOCK SWITCH
