Mazda CX-50 I (2021-2024) left rear auto down Wiring diagram
This page shows the only wiring diagram for the component.left rear auto down, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear auto down (1 of 1)
AUTO DOWN
AUTO UP
BLK WIRE
BLU WIRE
BRN WIRE
C-22
C-23
C-24
CAN L
CLOSE
COMPUTER DATA LINES SYSTEM
DRIVER'S FRONT DOOR)
DRIVER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT
FUSE 16
FUSE 9 FUSE 10
FUSE BLOCK
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILL 5
JOINT CONNECTOR C-46
LEFT FRONT
LEFT FRONT POWER WINDOW MOTOR
LEFT REAR AUTO DOWN
LEFT REAR AUTO UP
LEFT REAR MANUAL DOWN
LEFT REAR POWER WINDOW MOTOR
LEFT REAR POWER WINDOW SUBSWITCH
LT BLU WIRE
LT GRN WIRE
MANUAL AUTO UP UP
MANUAL DOWN
MANUAL UP
ORG/ WIRE
PNK WIRE
POWER WINDOW MAIN SWITCH
POWER-CUT SWITCH
PPL
PW FR CLOSE
PW FR OPEN
PW FR SW (WATER)
PW ILL 1
PW OUT
PW RR CLOSE
PW RR OPEN
PW RR SW
PW RR SW (WATER)
PW RR SW GND
PW SW D
PW SW P
PW SW RL
PW SW RR
RED WIRE
RIGHT FRONT
RIGHT FRONT RIGHT FRONT
RIGHT REAR AUTO DOWN
RIGHT REAR MANUAL UP
RIGHT RIGHT REAR REAR AUTO MANUAL UP DOWN
SW GND
VIO WIRE
WHT WIRE
Go to component -> Power windows circuit (1 of 2) -> LEFT REAR AUTO DOWN
