Mazda CX-50 I (2021-2024) humidity sensor/ solar radiation sensor/auto light sensor/ rain sensor Wiring diagram
This page shows the only wiring diagram for the component.humidity sensor/ solar radiation sensor/auto light sensor/ rain sensor, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram humidity sensor/ solar radiation sensor/auto light sensor/ rain sensor (1 of 1)
0140-442
0616-101
0616-102
0922-201
0922-205
0922-302
ACTIVE DRIVING DISPLAY
AUTO DIMMING REAR VIEW MIRROR
BLK WIRE
C-16
C-27
CLIMATE CONTROL UNIT
CLOCKSPRING
CLUSTER SWITCH 1
CLUSTER SWITCH 2
CONNECTIVITY MASTER UNIT SHIELD
CRUISE CONTROL SWITCH
DATA LINK CONNECTOR 2
DOWN SWITCH
ELECTRIC VARIABLE VALVE TIMING MOTOR/ DRIVER
ELECTRIC WATER PUMP
FORWARD SENSING CAMERA (FSC)
FRONT MAP LIGHT
GLASS MOTOR
HEATED STEERING WHEEL CONTROL UNIT
HORN (HIGH)
HUMIDITY SENSOR/ SOLAR RADIATION SENSOR/AUTO LIGHT SENSOR/ RAIN SENSOR
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
INDICATOR UNIT
INSTRUMENT CLUSTER
J/C C-55
NCA WIRE
PANORAMA SUNROOF SWITCH
PASSENGER COMPARTMENT TEMPERATURE SENSOR
PUSH BUTTON START
RIGHT FRONT PARKING/ TURN LIGHT
STEERING ANGLE SENSOR
STEERING SHIFT SWITCH
STEERING SWITCH
SUNSHADE MOTOR
UP SWITCH
Go to component: -> Ground distribution circuit (2 of 5) -> HUMIDITY SENSOR/ SOLAR RADIATION SENSOR/AUTO LIGHT SENSOR/ RAIN SENSOR
