Mazda CX-50 I (2021-2024) fuel-filler lid lock actuator Wiring diagrams

This page contains all the electrical diagrams for the component. fuel-filler lid lock actuator, in which he is found in the car Mazda CX-50 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram fuel-filler lid lock actuator (1 of 3)

Wiring diagram fuel-filler lid lock actuator for Mazda CX-50 I (2021-2024)

Get access

0914-118 BACKUP B+ MON BACKUP POWER SUPPLY (IF EQUIPPED) (UNDER DRIVER'S SEAT) BLK WIRE BLU WIRE BRN WIRE C-06 C-20 C-22 C-23 C-24 C-25 CAN-H 1 CAN-L 1 CARGO LAMP CARGO SW COMPUTER DATA LINES SYSTEM DOOR DOOR SW (RL) DOOR SW FL E LATCH MOTOR ELECTRICAL SUPPLY UNIT (LEFT SIDE OF LUGGAGE COMPT) FUEL LID L FUEL LID UL FUEL-FILLER LID LOCK ACTUATOR FUSE 48 GRN WIRE HOT W/ IGN 1 RELAY 2 ENERGIZED J/C C-51 J/C C-52 LATCH) LEFT REAR DOOR LATCH, LOCK ACTUATOR LIFTGATE DOOR LOCK SWITCH LIFTGATE LATCH, LOCK ACTUATOR LIFTGATE OPENER SWITCH LOCK LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RELAY & FUSE BLOCK RIGHT REAR DOOR LATCH, LOCK ACTUATOR UNLOCK VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Anti-theft circuit (3 of 4) -> FUEL-FILLER LID LOCK ACTUATOR

Wiring diagram fuel-filler lid lock actuator (2 of 3)

Wiring diagram fuel-filler lid lock actuator for Mazda CX-50 I (2021-2024)

Get access

0914-118 BACKUP B+ MON BACKUP POWER SUPPLY (IF EQUIPPED) (UNDER DRIVER'S SEAT) BLK WIRE BLU WIRE BRN WIRE C-06 C-20 C-22 C-23 C-24 C-25 CAN-H 1 CAN-L 1 CARGO LAMP CARGO SW COMPUTER DATA LINES SYSTEM DOOR DOOR SW (RL) DOOR SW FL E LATCH MOTOR ELECTRICAL SUPPLY UNIT (LEFT SIDE OF LUGGAGE COMPT) FUEL LID L FUEL LID UL FUEL-FILLER LID LOCK ACTUATOR FUSE 48 GRN WIRE HOT W/ IGN 1 RELAY 2 ENERGIZED J/C C-51 J/C C-52 LATCH) LEFT REAR DOOR LATCH, LOCK ACTUATOR LIFTGATE DOOR LOCK SWITCH LIFTGATE LATCH, LOCK ACTUATOR LIFTGATE OPENER SWITCH LOCK LT GRN WIRE NCA WIRE ORG/ WIRE PNK WIRE RED WIRE RELAY & FUSE BLOCK RIGHT REAR DOOR LATCH, LOCK ACTUATOR UNLOCK VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Power door locks circuit (3 of 4) -> FUEL-FILLER LID LOCK ACTUATOR

Wiring diagram fuel-filler lid lock actuator (3 of 3)

Wiring diagram fuel-filler lid lock actuator for Mazda CX-50 I (2021-2024)

Get access

0914-118 AUTO RETURN BLK WIRE BLU WIRE C-20 CAN H PBLC CAN L CAN L PBLC CARGO LAMP CARGO SW CLUSTER B SIG CLUSTER SWITCH 2 COMPUTER DATA LINES SYSTEM DOOR LOCK SWITCH (LIFTGATE)/ PLG REAR SWITCH E LATCH MOTOR ELECTRICAL SUPPLY UNIT FUEL LID L FUEL LID UL FUEL-FILLER LID LOCK ACTUATOR FUSE 17 FUSE 22 FUSE BLOCK GND WASHER GRN WIRE HOT AT ALL TIMES ILL PLUS INSTRUMENT CLUSTER J/C C-45 L/G LOCK SW LF CONTROL UNIT LIFTGATE LATCH, LOCK ACTUATOR LIFTGATE OPENER SWITCH LT GRN WIRE ORG/ WIRE PNK WIRE PPL/VIO WIRE RED WIRE RELAY & FUSE BLOCK TRUNK LID OPENER SWITCH (INTERIOR) / PLG FRONT SWITCH TRUNK UNLATCH SW VIO WIRE WHT WIRE YEL WIRE

Go to component: -> Trunk release circuit -> FUEL-FILLER LID LOCK ACTUATOR
