Mazda CX-50 I (2021-2024) driver-side front pre-tensioner seat belt Wiring diagram
This page shows the only wiring diagram for the component.driver-side front pre-tensioner seat belt, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver-side front pre-tensioner seat belt (1 of 1)
0810-109
BLK WIRE
BLU WIRE
BRN WIRE
C-61
DASH-ELECTRICAL SUPPLY UNIT
DRIVER SIDE CURTAIN AIR BAG MODULE
DRIVER-SIDE AIR BAG SENSOR 1
DRIVER-SIDE BUCKLE SWITCH
DRIVER-SIDE FRONT PRE-TENSIONER SEAT BELT
GRN WIRE
GRY WIRE
INFLATOR
INFLATOR 1
INFLATOR 2
LT BLU WIRE
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PASSENGER SIDE CURTAIN AIR BAG MODULE
PASSENGER-SIDE AIR BAG MODULE (ON RIGHT SIDE OF DASH)
PASSENGER-SIDE AIR BAG SENSOR 1
PASSENGER-SIDE FRONT PRE-TENSIONER SEAT BELT
PNK WIRE
SHORT BAR
VIO WIRE
YEL WIRE
Go to component -> Supplemental restraints circuit (3 of 4) -> DRIVER-SIDE FRONT PRE-TENSIONER SEAT BELT
