Mazda CX-50 I (2021-2024) driver side curtain air bag module Wiring diagram

This page shows the only wiring diagram for the component.driver side curtain air bag module, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver side curtain air bag module (1 of 1)

Wiring diagram driver side curtain air bag module for Mazda CX-50 I (2021-2024)

Get access

0810-109 BLK WIRE BLU WIRE BRN WIRE C-61 DASH-ELECTRICAL SUPPLY UNIT DRIVER SIDE CURTAIN AIR BAG MODULE DRIVER-SIDE AIR BAG SENSOR 1 DRIVER-SIDE BUCKLE SWITCH DRIVER-SIDE FRONT PRE-TENSIONER SEAT BELT GRN WIRE GRY WIRE INFLATOR INFLATOR 1 INFLATOR 2 LT BLU WIRE LT GRN WIRE NCA WIRE ORG/ WIRE PASSENGER SIDE CURTAIN AIR BAG MODULE PASSENGER-SIDE AIR BAG MODULE (ON RIGHT SIDE OF DASH) PASSENGER-SIDE AIR BAG SENSOR 1 PASSENGER-SIDE FRONT PRE-TENSIONER SEAT BELT PNK WIRE SHORT BAR VIO WIRE YEL WIRE

Go to component: -> Supplemental restraints circuit (3 of 4) -> DRIVER SIDE CURTAIN AIR BAG MODULE
