Mazda CX-50 I (2021-2024) can h ak pnk mot r b ap mot r a as Wiring diagram
This page shows the only wiring diagram for the component.can h ak pnk mot r b ap mot r a as, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram can h ak pnk mot r b ap mot r a as (1 of 1)
0412-104
0412-105
AD AUTO HOLD IND
AG IGN
AUTO HOLD IND
AUTO HOLD SW
AUTO RETURN SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
C-04
C-06
C-07
C-08
C-14
CAN H AK PNK MOT R B AP MOT R A AS WIRE
CAN L
COMPUTER DATA LINES SYSTEM
DSC HU/CM (RIGHT REAR OF ENGINE COMPT)
ELECTRIC PARKING BRAKE SWITCH (CENTER CONSOLE)
ELECTRICAL SUPPLY UNIT
FUSE 16
FUSE 17
FUSE 35
FUSE 48
FUSE 49
FUSE 50
FUSE BLOCK
GND VP
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
ILLUMINATION LIGHT
INDICATOR LIGHT
INSTRUMENT CLUSTER
J/C C-45
J/C C-46
LEFT ELECTRIC PARKING BRAKE MOTOR GEAR UNIT
LT BLU WIRE
LT GRN WIRE
MICROCOMPUTER
MOT L A
MOT L B
NCA WIRE
OPERATION SIDE
PNK WIRE
PPL/LT BLU WIRE
PPL/VIO WIRE
RED WIRE
RELAY & FUSE BLOCK
RELAY 2 ENERGIZED
RELEASE SIDE
RIGHT ELECTRIC PARKING BRAKE MOTOR GEAR UNIT
STOP SIG
VIO WIRE
WARNING/ INDICATOR LIGHTS
WHT WIRE
YEL WIRE
Go to component: -> Park brake release circuit -> CAN H AK PNK MOT R B AP MOT R A AS WIRE
