Mazda CX-50 I (2021-2024) 360 view monitor control module Wiring diagram
This page shows the only wiring diagram for the component.360 view monitor control module, which is found in the car Mazda CX-50 I (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 360 view monitor control module (1 of 1)
0140-416
360 VIEW MONITOR CONTROL MODULE
ACTIVE AIR SHUTTER
AFS CONTROL MODULE/AUTO LEVELING CONTROL MODULE
AUDIO AMPLIFIER
BACKUP POWER SUPPLY
BCM
BLK WIRE
BRAKE CONTROL ECU
BRAKE FLUID LEVEL SENSOR
BRAKE SWITCH
C-01
C-07
C-10
C-19
C-22
C-83
CARGO COMPARTMENT LIGHT (TRUNK COMPARTMENT SIDE)
DRIVER'S SIDE DOOR-ELECTRICAL SUPPLY UNIT
ELECTRIC AT OIL PUMP
ELECTRICAL SUPPLY UNIT
FRONT ACCESSORY SOCKET
FRONT RADAR SENSOR
GRY WIRE
HOOD LATCH SWITCH
HORN (LOW)
J/C C-29
J/C C-52
LEFT FRONT DOOR LATCH, LOCK ACTUATOR
LEFT FRONT PARKING/ TURN LIGHT
LEFT REAR COMBINATION LIGHT
NCA WIRE
PLG CONTROL MODULE
PPL/BLK WIRE
REAR ACCESSORY SOCKET
REAR SEAT WARMER SWITCH
REMOTE ENGINE START (OPTION)
RIGHT END OF DASH)
RIGHT REAR COMBINATION LIGHT
TCM
THEFT- DETERRENT HORN
USB POWER OUTLET
W/O BOSE AUDIO
W/O I-STOP
WASHER FLUID LEVEL SENSOR
Go to component: -> Ground distribution circuit (1 of 5) -> 360 VIEW MONITOR CONTROL MODULE
