Mazda CX-50 I (2021-2024) 0613-102 Wiring diagrams
This page contains all the electrical diagrams for the component. 0613-102, in which he is found in the car Mazda CX-50 I (2021-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 0613-102 (1 of 2)
0613-102
AK CAN H PBLC
AM CAN L PBLC
BLK WIRE
BLU WIRE
BRN WIRE
C-03
CAN L
COMPUTER DATA LINES SYSTEM
DC-DC CONVERTER
DCDC OUT
EPS CONTROL MODULE
FUSE 16
FUSE 19
FUSE 48
FUSE 49
FUSE 55
GND SIG AJ
HOT AT ALL TIMES
IG DCDC
IGNITION RELAY
INSTRUMENT CLUSTER
J/C C-41
LT GRN WIRE
MICROCOMPUTER
POWER DISTRIBUTION SYSTEM
PPL/GRN WIRE
RED WIRE
RELAY & FUSE BLOCK
RELAY 2 ENERGIZED
W/O I STOP SYSTEM
WARNING/ IND LIGHTS
WHT WIRE
YEL WIRE
Go to component -> Electronic power steering circuit -> 0613-102
Wiring diagram 0613-102 (2 of 2)
0613-102
2.5L
A/C RELAY
AFS CONTROL MODULE/ AUTO LEVELING CONTROL MODULE
BCM
BLK WIRE
BLOWER RELAY
BLU WIRE
BRN WIRE
C-03
C-05
C-08
C-10
C-69
C-70
ELECTRIC VARIABLE VALVE TIMING RELAY
EPS CONTROL UNIT
FROM BCM (DIAGRAM 3 OF 6)
FROM FUSE 28 (DIAGRAM 1 OF 6)
FRONT RADAR SENSOR
FUEL PUMP RELAY
FUSE 11
FUSE 19
FUSE 2
FUSE 20
FUSE 21
FUSE 24
FUSE 25
FUSE 29
FUSE 3
FUSE 30
FUSE 31
FUSE 37
FUSE 4
FUSE 40
FUSE 5
FUSE 53
FUSE 54
FUSE 7
GRN WIRE
GRY WIRE
HORN RELAY
J/C C-30
J/C C-58
LEFT FRONT PARKING/ TURN LIGHT
LEFT REAR SIDE RADAR SENSOR
LT GRN WIRE
MAIN RELAY
NCA WIRE
PARKING ASSIST UNIT
PCM
PNK WIRE
REAR ACCESSORY SOCKET
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY & FUSE BLOCK
RIGHT FRONT PARKING/ TURN LIGHT
RIGHT REAR SIDE RADAR SENSOR
SUB RELAY
VIO WIRE
W/ PARKING SENSOR
W/O PARKING SENSOR
WHT WIRE
WINDSHIELD WIPER DE-ICER RELAY
YEL WIRE
Go to component -> Power distribution circuit (2 of 6) -> 0613-102
