Car Wiring Diagrams for Parking assistant circuit for Mazda CX-5 II (2017-2022)

0922-612 22-PIN 18-PIN BLK WIRE BLU WIRE BRN WIRE C-04 C-24 C-36 C-39 C-93 C-94 COMPUTER DATA LINES SYSTEM FBZ FRONT PARKING SENSOR BUZZER GRN WIRE GRY WIRE IGR BZ J/C C-51 J/C C-56 J/C C-57 LEFT FRONT CORNER ULTRASONIC SENSOR LEFT FRONT ULTRASONIC SENSOR LT BLU WIRE LT GRN WIRE PARKING ASSIST UNIT PNK AA MS CAN-H AB MS CAN-L WIRE PNK WIRE PPL/PNK WIRE RBZ REAR PARKING SENSOR BUZZER RED WIRE RELAY & FUSE BLOCK RELAY ENERGIZED RIGHT END OF DASH) RIGHT FRONT CORNER ULTRASONIC SENSOR RIGHT FRONT ULTRASONIC SENSOR SYS SW TAN WIRE VIO WIRE WHT WIRE YEL WIRE

0922-613 22-PIN 18-PIN BLK WIRE BLU WIRE BRN WIRE C-04 CLUSTER SWITCH COMPUTER DATA LINES SYSTEM GRN WIRE GRY WIRE INDICATOR INSTRUMENT CLUSTER J/C C-58 LEFT REAR CORNER ULTRASONIC SENSOR LEFT REAR ULTRASONIC SENSOR LIGHTS) METER 1 FUSE MICROCOMPUTER PARKING SENSOR PNK WIRE PPL/PNK WIRE RED WIRE RELAY & FUSE BOX (F/B) RELAY ENERGIZED RIGHT REAR CORNER ULTRASONIC SENSOR RIGHT REAR ULTRASONIC SENSOR TAN WIRE VIO WIRE WARNING WHT WIRE YEL WIRE
