Car Wiring Diagrams for Memory systems circuit for Mazda CX-5 II (2017-2022)

+B (SYS) B+ PWR BACK BLK WIRE BLU WIRE BWD C-06 C-10 C-31 COMPUTER DATA LINES SYSTEM DOWN DRIVER-SIDE SEAT FRONT GRN WIRE HOT AT ALL TIMES HOT W/ HS CAN-H HS CAN-L J/C C-67 LIFT MOTOR, POSITION SENSOR LIFT POS SENS METER 1 FUSE NCA WIRE P-GND POS SENS PWR POSITION MEMORY CONTROL MODULE RECLINE POS SENS RECLINER MOTOR, POSITION SENSOR RED WIRE RELAY & FUSE BLOCK ROOM FUSE SET SW SLIDE MOTOR, POSITION SENSOR SLIDE POS SENS TILT MOTOR, POSITION SENSOR TILT POS ENS WHT WIRE

BACK BACK-UP C-31 DOWN DRIVER SIDE POWER SEAT SWITCH DRIVER-SIDE SEAT FRONT FUSE BLOCK GRN WIRE HOT AT ALL TIMES LIFT LUMBAR LUMBAR SUPPORT MOTOR MEMORY NCA WIRE P SEAT (D) FUSE POSITION MEMORY SWITCH RECLINER SET- SLIDE TILT UP DOWN
