Mazda CX-5 II (2017-2022) w/o garage door opener w/ 5 pin Wiring diagram
This page shows the only wiring diagram for the component.w/o garage door opener w/ 5 pin, which is found in the car Mazda CX-5 II (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o garage door opener w/ 5 pin (1 of 1)
AUTO DIMMING REAR VIEW MIRROR
BLK WIRE
BLU WIRE
BRN WIRE
C-04
C-14
C-19
C-24
C-95
CAN L
COMPUTER DATA LINES SYSTEM
HOT AT ALL TIMES
J/C C-51
J/C C-56
J/C C-60 (UPPER CENTER OF DASH)
PNK WIRE
RBCM
RELAY & FUSE BLOCK
RELAY ENERGIZED
REVERSE LAMP
ROOM FUSE
VIO WIRE
W/ SHORT CORD
W/O GARAGE DOOR OPENER W/ 5 PIN
Go to component -> Auto dimming mirror circuit -> W/O GARAGE DOOR OPENER W/ 5 PIN
