Mazda CX-5 II (2017-2022) urea level sensor/ urea temperature sensor/ urea tank heater Wiring diagrams

0740-201 0810-1018 18-PIN 22 PIN ACCESSORY SOCKET (CENTER) ACCESSORY SOCKET (REAR) AUTOMATIC A/C BLK WIRE BLOWER FAN CONTROLLER C-26 C-39 C-85 C-88 CLIMATE CONTROL UNIT DRIVER-SIDE BUCKLE SWITCH ELECTRIC PARKING BRAKE CONTROL MODULE ELECTRIC PARKING BRAKE SWITCH ELECTRIC VARIABLE VALVE TIMING MOTOR/ DRIVER EPS CONTROL MODULE FUEL PUMP CONTROL MODULE FUEL PUMP CONTROL MODULE SHIELD IGNITION COIL 1 IGNITION COIL 2 IGNITION COIL 3 IGNITION COIL 4 KEYLESS RECEIVER LEFT BLIND SPOT MONITORING CONTROL MODULE LEFT REAR COMBINATION LIGHT MANUAL A/C NCA WIRE OCCUPANCY SENSOR OCCUPANT CLASSIFICATION SENSOR CONTROL MODULE PASSENGER SIDE BUCKLE SWITCH PLC CONTROL MODULE (SHIELD) PLG CONTROL MODULE RIGHT BLIND SPOT MONITORING CONTROL MODULE RIGHT REAR COMBINATION LIGHT SAS CONTROL MODULE UREA HOSE (BUILT IN HEATER) UREA LEVEL SENSOR/ UREA TEMPERATURE SENSOR/ UREA TANK HEATER W/ OCCUPANCY CLASSIFICATION SENSOR W/ OCCUPANCY SENSOR

AAT ACCELERATOR PEDAL POSITION SENSOR ACPS AIR CONDITIONING SYSTEM AMBIENT TEMPERATURE SENSOR BLK WIRE BLOW-BY HEATER BLU WIRE BOOST AIR TEMPERATURE SENSOR BRAKE SWITCH BRN WIRE C-02 C-85 C-86 C-88 CLCN CLCUT/ COMPUTER DATA LINES SYSTEM COOLING FAN RELAY 1 COOLING FAN RELAY 2 COOLING FANS SYSTEM E(AAT) E(ACPS,MVCP) E(THRCOL) FCM RLY GLOW FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES LT GRN WIRE MAIN FUSE ON BATTERY) PCM PNK WIRE RED WIRE REFRIGERANT PRESSURE SENSOR RIGHT RELAY BOX STA RLY STARTING/CHARGING SYSTEM UREA HOSE UREA LEVEL SENSOR/ UREA TEMPERATURE SENSOR/ UREA TANK HEATER VIO WIRE VREF(ACPS,MVCP, CSS) WHT WIRE YEL WIRE
