Mazda CX-5 II (2017-2022) right rear foot light Wiring diagrams
This page contains all the electrical diagrams for the component. right rear foot light, in which he is found in the car Mazda CX-5 II (2017-2022). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear foot light (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
C-04
C-16
C-33
C-36
C-96
C-97
CAN L
CARGO COMPARTMENT LIGHT
COMPUTER DATA LINES SYSTEM
FBCM
GLOVE COMPARTMENT LIGHT
GRN WIRE
ILL
INSTRUMENT ILLUMINATION CIRCUIT
J/C C-61
LEFT
LEFT FRONT FOOT LIGHT
LEFT REAR FOOT LIGHT
LEFT VANITY MIRROR ILLUMINATION
LEFT VANITY MIRROR ILLUMINATION SWITCH
LT GRN WIRE
NCA WIRE
OFF ON
ON OFF
PNK WIRE
REAR MAP LIGHT
RED WIRE
RIGHT
RIGHT FRONT FOOT LIGHT
RIGHT REAR FOOT LIGHT
RIGHT VANITY MIRROR ILLUMINATION
RIGHT VANITY MIRROR ILLUMINATION SWITCH
TAN WIRE
W/ LED
W/O LED
WHT WIRE
YEL WIRE
Go to component -> Courtesy lamps circuit (2 of 2) -> RIGHT REAR FOOT LIGHT
Wiring diagram right rear foot light (2 of 2)
0518-101
0912-402
2-PIN
8-PIN
BLK WIRE
C-27
C-31
C-32
C-33
C-96
DRIVE SELECTION SWITCH
DRIVER SIDE SEAT WARMER UNIT
DRIVER-SIDE SEAT VENTILATION UNIT (SEAT BACK SIDE)
DRIVER-SIDE SEAT VENTILATION UNIT (SEAT CUSHION SIDE)
FRONT SEAT WARMER CONTROL UNIT
GLOVE COMPONENT LIGHT
GRY WIRE
HAZARD WARNING SWITCH
INDICATOR UNIT
LEFT FRONT FOOT LIGHT
LEFT REAR FOOT LIGHT
NCA WIRE
PARKING ASSIST UNIT
PASSENGER SIDE POWER SEAT SWITCH
PASSENGER-SIDE SEAT VENTILATION UNIT (SEAT BACK SIDE)
PASSENGER-SIDE SEAT VENTILATION UNIT (SEAT CUSHION SIDE)
POSITION MEMORY CONTROL MODULE
POWER SEAT SWITCH
PUSH BUTTON START
RIGHT DOOR LOCK SWITCH
RIGHT FRONT FOOT LIGHT
RIGHT FRONT POWER WINDOW SUB SWITCH
RIGHT REAR FOOT LIGHT
RIGHT SIDE TURN LIGHT
SELECTOR LEVER COMPONENT
SHIFT PANEL (INDICATOR)
Go to component -> Ground distribution circuit (1 of 7) -> RIGHT REAR FOOT LIGHT
