Mazda CX-5 II (2017-2022) power liftgate latch switch Wiring diagram
This page shows the only wiring diagram for the component.power liftgate latch switch, which is found in the car Mazda CX-5 II (2017-2022). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram power liftgate latch switch (1 of 1)
0912-401
0918-802
AWD CONTROL MODULE
BLK WIRE
BLK/YEL WIRE
C-27
C-28
C-29
C-30
C-37
C-44
C-45
HIGH MOUNT BRAKE LIGHT
LEFT DOOR LOCK SWITCH/ POWER WINDOW MAIN SWITCH/ POWER OUTER MIRROR SWITCH
LEFT FRONT DOOR LATCH, LOCK ACTUATOR
LEFT FRONT OUTER HANDLE
LEFT LICENSE PLATE LIGHT
LEFT LIFTGATE LIGHT
LEFT REAR DOOR LATCH, LOCK ACTUATOR
LEFT TURN LIGHT
LIFTGATE LATCH SWITCH
LIFTGATE LATCH, LOCK ACTUATOR
LIFTGATE LOCK ACTUATOR (SHIELD)
LIFTGATE OPEN SWITCH
LIFTGATE OPENER SWITCH
LIFTGATE REQUEST SWITCH
NCA WIRE
POWER LIFTGATE BUZZER
POWER LIFTGATE LATCH SWITCH
REAR WINDOW DEFOGGER
REAR WIPER MOTOR
RIGHT DOOR LOCK SWITCH
RIGHT END OF DASH)
RIGHT FRONT DOOR LATCH, LOCK ACTUATOR
RIGHT FRONT OUTER HANDLE
RIGHT LICENSE PLATE LIGHT
RIGHT LIFTGATE LIGHT
RIGHT REAR DOOR LATCH, LOCK ACTUATOR
RIGHT REAR POWER WINDOW SUB SWITCH
W/ DRIVER SIDE WINDOW AUTO OPEN/CLOSE
WHT WIRE
Go to component -> Ground distribution circuit (5 of 7) -> POWER LIFTGATE LATCH SWITCH
